Application Solutions2D Shape

For Individuals Looking at 2D Shape Measurement Systems

When looking for the best way to perform profile measurements, there are a number of important factors to consider, including the type of measurement system and the installation environment. Selecting equipment that doesn't adequately meet your needs can lead to insufficient precision and increased man-hours during production. This site is designed to help users determine the best way to perform measurements with confidence in regards to a 2D shape measurement system.

How to Measure 2D Shapes

  • STEP 1: Look at the outlined methods in each item to find the best measurement method for the application at hand.
  • STEP 2: Download the relevant measurement system catalogue.
  1. A- Measurement using a 1D displacement laser B- Measurement using a 2D laser displacement sensor
  2. Example Applications
    • A- Measurement 1 Profile measurement of aluminium fins
    • B- Measurement 2 Profile measurement of tyre tread grooves
